Swing Arm & Shocks

Swing Arm and shocks for 1976-77 Kawasaki KZ900 A4 / A5

Back to Contents

Kits & Used

kz900 swing-arm-shocks
Ref OEM Part Name Req
1 33001-046 Arm, Swing 1
2 33032-036 Shaft, Swing Arm Pivot 1
3 33035-007 Cap, Swing Arm 2
4 671B2530 "0" Ring, 30mm 2
5 33034-009 Sleeve Swing Arm 2
6 33033-009 Bushing-Swing Arm 2
7 33036-005 Collar, Swing Arm 1
8 92019-012 Nut-Self Locking 1
9 33040-066 Adjuster, Chain 2
10 92001-143 Bolt-Chain Adjust 10mm 2
11 33044-001 Stopper, Chain Adjust 2
12 315B1000 Nut 10mm 2
13 92001-1578 Bolt (92002-1838) 2
14 461F0800 Washer Spring 8mm 2
15 92005-002 Grease Nipple 1
16 45014-107 Shock Absorber Rear 2
17 92020-014 Nut 12mm 2
18 113N1035 Bolt Hex Head 10x35 (112N1035) 2
20 461F1200 Washer Spring 12mm 2
21 410B1200 Washer Plain 12mm 4
22 45017-001 Bush Shock Absorber Rubber 4
23 45017-011 Bushing, Shock Absorber 2
24 45016-003 Bush Shock Absorber Pivot Shaft 2
25 43007-032 Torque Link, Rear Brake 1
26 92003-103 Bolt Torque Link Fitting 1
27 411B1000 Washer Plain 10mm 1
28 92003-147 Bolt, Torque Link 1
29 314B1000 Nut, 10mm 2
30 554A0800 Pin, Snap 2
31 461F1000 Washer Spring 10mm 2
Kits

zoom

Drive Chain Adjuster Assembly (Pair) 33040-066 for 73-80 Kawasaki Z1 / KZ900 / KZ1000

$92.99




Replaces
45014-107

Shocks, Rear Chrome KZ9000000(13.5" Eye to Eye)
Chrome classic type shock body with 5-position spring pre-load adjustment. Progressive Heavy-Duty chrome springs. 365mm (13 1/2") Eye to Eye. Fits Kawasaki models: 73-75 Z1, 76-77 KZ900, 80-81 GPZ550, 80-83 KZ550A, 82 GPZ750, 80-83 KZ750E, 80-83 KZ750H, 78-80 Z1R, 79-83 KZ1000 A/B/D/G/J/K/M, 81-82 GPZ1100, 81-83 KZ1100 Shaft.

KZ900 Chrome Shocks, Pair of EM17-05691 $169.99 pair
not currently available





Rear Shocks with Reflector, Chrome Z1 (13.5" Eye to Eye)
Rear chrome shocks for all models above, 365mm (13 1/2" Eye to Eye). These are like the ones used from the factory on the Z1 models from 1973-75. Also fits the above models.

13.5 Z1 Pair of Rear Chrome Shocks with Reflectors EM17-05690 $169.99 pair
not currently available



Swing Arm Bearing Kit for 1973-77 Kawasaki Z1/KZ900

Swing Arm Bearing Kit
Contains shaft, 4 needle bearings, 2 spacers & 2 thrust washers. Fits Z1 / KZ900.

Swing Arm Bearing Kit KZ900 KL31-6924 $169.99



Swing Arm Bearing Kit for Kawasaki KZ1000

Swing Arm Needle Bearing
Set of Swing Arm Needle Bearings KZ250 L1/W1, EX305 B1, KZ305 A1/A2/B1/B2/B3, KZ400 B1/B2/C1/H1, KZ440 A1/A2/A3/A4/B1/B2/D1-D5, EN450 A1-A6, KZ550 A1/A2/A3/A4/C1/C2/C3/C4/D1, KZ650 E1/F1/H1/H2/H3/ KZ700A1, KZ750 B3/B4/E1/E2/E3/G1/H1/H2/H3/H4/L3, KZ1000 A1/A2/A2A/A3/A3A/A4/ B1/B2/B3/B4/ C1/C1A/C2/C3/C4/ D1/D3/ G1.

Swing Arm Needle Bearing KL31-0828 $119.99
Used Parts

zoom
33040-066

Used Drive Chain Adjuster Assembly (Pair) 73-80 Kawasaki Z1 / KZ900 / KZ1000. Photo is not actual and not as nice looking.

Used Drive Chain Adjusters (pair) 33040-066 $45.00
